Technical | Model | RZBR130M-1(V/H) | RZBR150M-1(V/H) | RZBR180M-1(V/H) | RZBR1100M-1(V/H) | |
Rated Capacity(L) | 30 | 50 | 80 | 100 | ||
Rated Power(KW) | 0.7/1.3/2KW | 0.7/1.3/2KW | 0.7/1.3/2KW | 0.7/1.3/2KW | ||
Votage(V~) | 220V~ | 220V~ | 220V~ | 220V~ | ||
Current(A) | 3.2/6/9.1A | 3.2/6/9.1A | 3.2/6/9.1A | 3.2/6/9.1A | ||
Frequency(Hz) | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz | ||
Polyurethane Foam(mm) | 20mm | 20mm | 20mm | 20mm | ||
Stainless | Vertical | Dimensions(mm) | 435×55×235 | 435×825×235 | 498×955×272 | 498×1155×272 |
Carton(mm) | 493×685×310 | 493×955×310 | 553×1085×345 | 553×1285×345 | ||
Load Qty(40HQ) | 649 | 465 | 328 | 277 | ||
Horizontal | Dimensions(mm | 555×435×235 | 825×435×235 | 955×498×272 | 1155×498×272 | |
Carton(mm) | 685×493×310 | 955×493×310 | 1085×553×345 | 1285×553×345 | ||
Load Qty(40HQ) | 649 | 465 | 328 | 277 | ||
Enamel Tank | Vertical | Dimensions(mm | 450×650×240 | 530×710×280 | 530×1020×280 | 530×1225×280 |
Carton(mm) | 520×715×320 | 605×788×365 | 605×1110×365 | 605×1315×365 | ||
Load Qty(40HQ) | 570 | 390 | 277 | 234 | ||
Horizontal | Dimensions(mm) | 650×450×240 | 710×530×280 | 1020×530×280 | 1225×530×280 | |
Carton(mm) | 715×520×320 | 788×605×365 | 1110×605×365 | 1315×605×365 | ||
Load Qty(40HQ) | 570 | 390 | 277 | 234 | ||
PRODUCT FEATURE | Double tanks | |||||
