Technical | Model | RZBR230M-1 | RZBR250M-1 | RZBR280M-1 | RZBR2100M-1 | |
Rated Capacity(L) | 30 | 50 | 80 | 100 | ||
Rated Power(kW) | 0.7/1.3/2KW | 0.7/1.3/2KW | 0.7/1.3/2KW | 0.7/1.3/2KW | ||
Voltage(V~) | 220V~ | 220V~ | 220V~ | 220V~ | ||
Current(A) | 3.2/6/9.1A | 3.2/6/9.1A | 3.2/6/9.1A | 3.2/6/9.1A | ||
Frequency(Hz) | 50-60Hz | 50-60Hz | 50-60H₂ | 50-60Hz | ||
Polyurethane Foam(mm) | 20mm | 20mm | 20mm | 20mm | ||
Stainless | Vertical | Dimensions(mm) | 435×630×235 | 435×855×235 | 498×985×272 | 498×1185×272 |
Carton(mm) | 510×700×315 | 510×925×315 | 510×700×350 | 555×1255×350 | ||
Load Qty(40HQ ) | 604 | 457 | 331 | 278 | ||
Horizontal | Dimensions(mm | 630×435×235 | 855×435×235 | 985×498×272 | 1185×498×272 | |
Carton(mm) | 700×510×315 | 925×510×315 | 1055×555×350 | 1255×555×350 | ||
Load Qty(40HQ ) | 604 | 457 | 331 | 278 | ||
Enamel Tank | Vertical | Dimensions(mm | 454×647×240 | 534×715×280 | 534×1021×280 | 534×1321×280 |
Carton(mm) | 520×691×320 | 605×788×365 | 605×1095×365 | 605×1305×365 | ||
Load Qty(40HQ ) | 619 | 396 | 289 | 237 | ||
Horizontal | Dimensions(mm) | 647×454×240 | 715×534×280 | 1021×534×280 | 1231×534×280 | |
Carton(mm) | 691×520×320 | 788×605×365 | 1095×605×365 | 1305×605×365 | ||
Load Qty(40HQ ) | 619 | 396 | 289 | 237 | ||
PRODUCT FEATURE | Double tanks | |||||
